Mini Electric Chain Hoist
The export-grade mini electric chain hoist, manufactured by Hebei Shengyu, is a lightweight lifting hoist designed for the global overseas market, primarily targeting Europe, America, Southeast Asia, and the Middle East. Its main advantages are safety, reliability, small size, light weight, and ease of operation. With a rated load of 250kg-1t and compatible with 220V household voltage, it enables short-distance handling and lifting of goods. It is widely used in warehousing, household applications, and small warehouses.
The export-grade mini electric chain hoist has a rated load range of 250kg-1000kg. It is manufactured by Hebei Shengyu Factory specifically for export, featuring a small size and light weight (approximately 10-20kg/unit). It is safe and reliable, equipped with dual brakes, and suitable for ordinary household voltage (220V/110V). This electric lifting device is specifically developed for lightweight lifting scenarios overseas. It can be manually controlled or equipped with wireless remote control to achieve vertical lifting or short-term horizontal movement of goods. This hoist also offers customization options for lifting weight, height, signage, logo, etc., to meet the diverse needs of different customers.
Core Competitive Advantages for Export
1. Lightweight: The mini electric chain hoist unit weighs only 10-20kg, made of aluminum alloy. Compared to the 30kg body of ordinary electric hoists, it is much lighter and has lower transportation costs.
2. Voltage Compatibility: Compatible with single-phase voltages such as 110V/220V/230V. Covers different needs in different countries and effectively solves the problem of voltage incompatibility in different regions.
3. Safety and Compliance: Dual brakes with a lower limit switch, and made of G80 grade alloy steel, providing a safety factor of ≥3 times and reducing usage risks.
4. High Cost-Effectiveness: FOB China port price is 80-180 USD/unit (basic configuration), which is 30-50% lower than European and American domestic brands, while maintaining quality and durability, meeting the cost-effectiveness needs of overseas small and medium-sized customers and e-commerce channels.
5. Simple Operation: No professional training required; simply read the instruction manual and watch the usage videos to operate.
Parameters
| Parameter | 250kg | 500kg(Export) | 1000kg |
| Rated Load | 250kg | 500kg | 1000kg |
| Power Supply | 110/220/230V 1Ph,50/60Hz | 110/220/230V 1Ph,50/60Hz | 110/220/230V 1Ph,50/60Hz |
| Lifting Speed | 6-8 m/min | 4-6 m/min | 4-5 m/min |
| Standard Lift Height | 3/6m | 3/6/9m | 3/6/9m |
| Chain Spec | Grade 80 Alloy Steel,φ6mm | Grade 80 Alloy Steel,φ7mm | Grade 80 Alloy Steel,φ8mm |
| Hoist Weight | 10-12kg | 14-16kg | 18-20kg |
| Control Mode | Pendant/Wireless Remote | Pendant/Wireless Remote | Pendant/Wireless Remote |
| Safety Features | Dual Brake,Limit Switches,Safety Latch | Dual Brake,Limit Switches,Safety Latch | Dual Brake,Limit Switches,Safety Latch |
| Serial No. | Component | Core Specifications & Features |
| 1 | Power System | Single-phase asynchronous motor, fits 110V/220V/230V export voltages; low power/energy consumption, good heat dissipation. Gear reduction for stable lifting, low noise. |
| 2 | Lifting System | Grade 80 φ6-8mm alloy steel chain, high strength/wear/corrosion resistance, safety factor ≥3, customizable length. Anti-shedding hook, meets CE safety standards. |
| 3 | Braking System | Dual brake (electromagnetic + mechanical), power-off instant stop, sensitive braking, prevents load slippage, ensures safety. Mandatory for EU export. |
| 4 | Control System | 2 options: basic manual button, upgraded wireless remote control; easy operation, remote control for long-distance use. English-marked buttons, meets export standards. |
| 5 | Body Structure | Aluminum alloy shell, lightweight/portable, good heat dissipation, reduces overall weight. Built-in up/down limit switches, prevents over-operation damage. |
| 6 | Auxiliary Components | Top hook/lifting ring for easy installation; English nameplate with rated load/voltage/certification info, meets export customs & market access requirements. |
Customizable Features:
1. Load Capacity Customization: Standard load capacities of the mini electric chain hoists are 250kg/500kg/1000kg. Special load capacities such as 300kg and 800kg are available upon request, provided by the customer.
2. Lifting Height Customization: Standard heights are 3m/6m/9m. Other heights can be customized to meet customer needs.
3. Control Method Customization: The basic model uses manual buttons; a wireless remote control can be added.
4. Appearance/Icons Customization: Body color, customer brand, logo, packaging, etc., can all be customized.
