10-ton Chain Hoist

The 10-ton chain hoist as the flagship products of Hebei Baiyi factory. It is a heavy-duty lifting tool that is purely manual, requires no power supply, features a self-locking safety mechanism, is easy to carry, and is relatively lightweight. It relies on manual pulling of the chain to drive an internal gear set, enabling the lifting chain to rise and fall vertically or hover briefly in the air. The core advantages of the 10T chain hoist are compact structure, lightweight, low pulling force, easy to carry and move, reliable braking, and simple maintenance.

Details data for 10 T chain hoist

Parameter Item Standard Value (10T) Remarks

Rated Load Capacity 10,000 kg (10T) Overloading is strictly prohibited

Standard Lifting Height 3 m Customizable: 6/9/12 m

Test Load 12.5 T 1.25 times rated load test

Hand Chain Pull Force at Full Load ≤ 392 N (≈40 kgf) Labor-saving design

Net Weight ≈ 70–85 kg Slight variations due to brand/structure

Key Selling Points

1. Safety: Reliable braking and fall protection ensure safe use.

Both the chain and hook are made of standard-compliant manganese steel. All undergo rigorous quality control before leaving the factory.

2. User Experience: The double ratchet design requires minimal pulling effort, making it very easy to operate. The chain is very smooth and does not jam.

The machine itself is lightweight and portable, and easy to operate, even for beginners.

3. Durability and Maintenance: Gears and bearings are made of high-quality materials, suitable for use in humid and dusty environments. One-year warranty provides peace of mind for customers.

Maintenance

1. Before use 10-ton chain hoist, check to ensure the chain is free from twisting, cracks, and severe wear; the hook is not deformed; and the brakes are effective.

2. After use, wipe all parts clean of dust, oil, and dirt.

3. Regularly apply a special anti-rust lubricant to the chain; ensure the brake friction pads are free of oil.

4. If long time no use for 10-ton chain hoist store in a dry, well-ventilated place, and wind the chain neatly.

Typical Application Scenarios

Industrial Manufacturing: Installation and handling of factory machinery, molds, equipment, and parts.

Construction Engineering: Installation of cement or steel structures, road and bridge construction.

Mining/Underground: Installation of tunnel equipment, hoisting of various equipment and ore, and lifting and moving materials in confined spaces.

Logistics and Warehousing: Placement of heavy goods in warehouses, loading and unloading of container pallets.

Ports and Terminals: Cargo loading and unloading, installation and maintenance of marine equipment, and other operations in areas without power supply.

FAQ

Q1: Can a 10-ton chain hoist pull heavy objects at an angle?

A: No. Pulling at an angle will cause the chain to twist and become unevenly stressed, leading to chain jamming, breakage, or overturning. It can only be used for vertical lifting.

Q2: What if the chain won't move?

A: Check if the load exceeds 10 tons, and if the chain is twisted or jammed. Check for damage to the internal gears.

Q3: What should I do if the brake fails or the load slips?

A: Stop work immediately and slowly lower the load. Check if the brake friction pads, ratchet, and pawl are oily or severely worn; replace worn parts. It can only be used after passing a test.

Q4: Can a 10T chain hoist be used with a monorail trolley?

A: Yes. It can be used with a 10T hand-operated monorail trolley.
